PRA-00290
Power supply: 230 V AC, 50 Hz
Power consumption: 20 W
Operation modes: 2-way stereo or 3-way mono
Inputs: XLR, electronically balanced/unbalanced
Impedance: Balanced >50 kohms, unbalanced >25 kohms
Max. input level: +22 dBu typical, balanced or unbalanced
Outputs: XLR, electronically balanced/unbalanced
Impedance: Balanced 200 ohms, unbalanced 100 ohms
Max. output level: >+21 dBu balanced/unbalanced into 2 kohms or greater
S/N ratio: >100 dB
THD: 0.05%
Crosstalk: >80 dB, -3 dB
Crossover frequencies: 45 Hz – 9.6 kHz
Filter type: Linkwitz-Riley, 24 dB/octave, state-variable
Low cut: 40 Hz Butterworth, 12 dB/octave
Phase invert: Per output
Input gain: -±12 dB
Output gain: – ~ to +6 dB
Dimensions (WxDxH): 483 x 152 x 48 mm
Weight: 1.8 kg
