• Low profile for minimum visibility
• Wide-range condenser element with low-mass diaphragm for superior performance
• Self-contained electronics eliminate need for external power modules
• Rugged design and construction
• 25’ (7.6 m) detachable cable (TA3F to XLRM-type)
Microphones
Element: Condenser
Polar Pattern: Half-cardioid (cardioid in hemisphere above mounting surface)
Frequency Response: 70 – 16,000 Hz
Open Circuit Sensitivity: -25dB (56.2mV) re 1V at 1 Pa
Maximum Input Sound Level: 114 dB SPL, 1 kHz at 1% T.H.D.
Dynamic Range: 86 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio: 66 dB, 1 kHz at 1 Pa
Phantom Power Requirements: 9-52V, 2 mA typical
Weight: 67 g
Cable: 25’ (7.6 m) long, with TA3F and XLRM-type connectors
Dimensions: 2.87” (73.0 mm) maximum width, 3.56” (90.5 mm) maximum length, 0.59” (15.0 mm) height
Output Connector: Integral 3-pin XLRM-type
