Electrical
Voltage: 100V-240V 50-60Hz
Amperage: 2.5A
Power consumption: 350W
Light source
LED lifespan: 50000 hours
LED: 7pcs x 40W Osram
Color: RGBW 4in1
Optical system
Control channels: Standard mode 17CH/ extended mode 38 CH/pattern mode 18CH/ HSI mode 11CH
DMX512: √
Master/slave: √
Network function: Support RDM and DMX software upgrade,Artnet,Klingnet, SACN networking protocol optional.
Touch screen Display: 2.0 inch LCD color screen, can set the channel mode (standard/extended/pattern/HSI) horizontal vertical inversion, back screen, signal hint, switch in both Chinese and English, automatic screen off/lasting bright screen, display channel mode,light source temperature, fan speed, record boot time, and times of start,fault inspection, manual control channel data memory, the software version information, restore factory Settings, scan and color correction.
Beam angle (scan type): 9°-44°/0.8s
Dimmer: 0-100% (16bit)
CCT: 2800K-8500K
Zoom: Using highly mute motor; accurate zoom, stable beam without shaking
X/Y scan: Pan 540°,Tilt:270°
Strobe: 1-20Hz
Features: 1.High efficiency cooling system, whole-process temperature monitoring.
2.Automatic temperature adjustment and protection when temperature is too high, no risk of LED lamp damage.
3.Intelligent speed control fan(SUNON FAN), timely display rotation speed.
Physical
Machine size: 29*22.5*38cm
Machine N.W.: 8.9kg
Housing: Flame-retardant plastic
Environment & safety
Store condition: Dry and clean place
Running temp.: 0-40°C
IP rate: IP20
