• Authentic High-Fidelity Amplification System
• Enjoy Pure Analog Playback of Vinyl Records
• Wolfson Digital-to-Analog Converter
• Separate Headphone Amplification Circuitry
• Quality Construction Equals Better Performance




ADVANCED FEATURES
44 W/Ch (8 Ω, 1 kHz, 0.08% THD, 2 Channels Driven, IEC)
WRAT (Wide Range Amplifier Technology) with Discrete Amplifier Output Circuitry
High Quality Wolfson WM8718 192 kHz/24-bit Digital-to-Analog Converter
Two Digital Audio Inputs (Optical and Coaxial)
Coaxial Supports Sampling Rates Up to 192 kHz/24-bit (Optical 96 kHz/24-bit)
Independent Headphone Amplification Circuitry
High-Current Low-Impedance Drive
Four Audio-Grade Capacitors
Extruded Aluminum Heat Sink
Thick Speaker Plates To Maintain Signal Quality
Gold-Plated Screw-type Banana Plug-Compatible Speaker Posts
Automatic Digital Circuitry Shutdown Function for Pure Analog Sound
Tone Controls (Bass/Treble/Balance)
5 Analog Audio Inputs (4 Rear / 1 Front) and 1 Output (Rear)
Phono Input (MM) and Phono Equalizer
6.3 mm Headphone Jack
RI (Remote Interactive) Remote Control
Low 0.4 W Power Consumption on Standby

SPECIFICATIONS
Power Output: 44 W/Ch (8 Ω, 1 kHz, 0.08% THD, 2 Channels Driven, IEC)
THD+N (Total Harmonic Distortion + Noise): 0.08% (1 kHz, 1 W Output)
Damping Factor: 95 (1 kHz, 8 Ω)
Input Sensitivity and Impedance:
150 mV/100 kΩ (Line)
3.0 mV/47 kΩ (Phono MM)
Rated RCA Output Level and Impedance:
0.15 V/2.2 kΩ (Line Out)
Phono Overload: 94 mV (MM, 1 kHz, 0.5%)
Frequency Response: 10 Hz−100 kHz/+1 dB, -3 dB (Line 1)
Tone Control:
±10 dB, 100 Hz (Bass)
±10 dB, 10 kHz (Treble)
Signal-to-Noise Ratio:
92 dB (Line, IHF-A)
78 dB (Phono MM, IHF-A)
Speaker Impedance: 4 Ω–16 Ω

General
Power Supply: AC 220–240V~, 50/60 Hz
Power Consumption: 155 W
No-Sound Power Consumption: 25 W
Standby Power Consumption: 0.4 W
Dimensions (W x H x D): 435 x 129.5 x 332.5 mm
Weight: 6.5 kg

A-9010 (B) Crna
A-9010 (S) Siva
